The series spot welding machine, the main transformer silicon rails are cold copper imports, therefore, the main power transformer small, all types of small no-load current.
·The series spot welding machine thyristor main circuit are non-contact switch, the circuit turn-off time for fast, accurate and reliable. Welding time can be accurate from time to time adjustment, Welding reproducible, and easy maintenance, high-quality welding can be achieved.
·The series spot welding machine can weld carbon steel, stainless steel, metal and many other black, non-ferrous, rare, precious metals and alloys. A wide range of steel furniture is better than the current,
Power distribution cabinets, the production of anti-theft doors, kitchen equipment and repair welding of steel wire mesh, such as tablets.
·Especially suitable for thin, medium and thick plate for welding and spot welding gap, and its reliability, stability, maintenance is simple, is the ideal choice for your welding equipment.
Suitable for welding carbon steel, stainless steel,
galvanizing plate etc, if add some flux and properly adjust the power source and weld time, various
Ferrous/nonferrous metal, rare metal such as gold, silver etc, could be welded.
Suitable for welding of work piece in different position or complex structure.
Two welding guns with different structure, more flexible to weld various work pieces.
| DN Series Spot Welding Machine
DN series spot welding machine has a pedal transmission lever, applying to spot welding parts of low carbon and non-ferrous metal. It has such advantages as simple structure, easy operation, low failure rate and low price.
DN2-25 portable precision spot welding machine is a new welding equipment controlled by controlled silicon. The welding machine is facilitated with adjusting installation showing the quantity of heat and welding time. It is widely used in spot welding of thin plate material for filing cabinets and switch cabinets.
With flexible cable of three meters between welding electrode and the main unit, the welding can be done at any place. The welding machine has such properties as excellent welding spot and easy and flexible operation.
|
|
| Model |
Power Voltage
V |
Adjusting
Series |
Continuous Loading Rate % |
Specified Capacity KVA |
Welding Thickness |
| DN-16 |
380 |
6 |
20 |
16 |
0.5Excluding0.5~2.0Excluding2.0 |
| DN-25 |
380 |
6 |
20 |
25 |
1Excluding1~2.5Excluding2.5 |
| DN5-40 |
380 |
Continuous non-grade |
20 |
40 |
0.2Excluding0.2~3Excluding3 |
| DN-40 |
380 |
8 |
50 |
40 |
2.5Excluding2.5 |
|
